Files for the Final Project
All files
File |
Linked |
Use |
Process |
| FlowMeter+Pin4 | Yes | Understand realtime water use at the point where sensor is installed | Coding |
| Distance Sensor+Pin4 | Yes | Understand the amount of water left in the tank | Coding |
| Relay+Pin4 | Yes | Understand realtime water use at the point where sensor is installed | Coding |
| Board Design Files | Yes | Board design files | Milling |
| Casing Design Files | Yes | Casign design files | Laser Cutting, 3mm acrylic |
| Server Files | Yes | Backend Server code - Python MQTT recieve, Relay message and logic code | Coding |
| printed case | Yes | 3D printed case for the tank level monitor | Coding |
