Electronics design

This week's task is to Redraw the echo hello-world board, add (at least) a button and LED (with current-limiting resistor), check the design rules, and make it.


Step1: Preparing My Eagle

  1. I free download Eagle software. It's a software tool used for circuit designing.
  2. After downloading Eagle and installing it I needed to restart my computer as the Eagle software asked me to do that.
  3. After restarting my computer I found the Eagle shortcut on the desktop.
  4. I downloaded the Fab library (you will find it in the downloads section at the end of this page) then made the following to be able to open it on Eagle : Copy> go to C:\EAGLE 8.0.2\lbr> paste.
  5. open Eagle > Under te library list you will find a library named fab > click on the grey circle infront of it> the circle will turn on green > now you can use the library in your designs.
This is the eagle icon.

This is the eagle icon.
