Output device

Im focusing this week to make part of my final project (You can check my project with the "Final Project!" tab). Will be desingning a board to make the stepper motors to work.

By the time this is being written, I not sure if my project "hand" will need 5 o 4 stepper motors, so I will be designing the board to withstand 5 if ever needed.

I will not be produce an integrated board. I already have a Fabduino, so adding a stepper motor board is a better choice.

Board Desing

First, I will desing the board using Eagle.

Comments

Have some issues with tabs that where half thickness. The software could not process naturally and a sub routine have to be added manually to avoid problems.

As said before, I remove the slot's relief ears to be added in this part, but we forgot to do that.
