Final Project

what will it do?

Is a prototype modular inflatable system called Smartbeddo that allows to achieve patient comfort and facilitates nurses’ work from a mobile phone. Through programming nurses and family can accommodate patients who are bedridden, controlling modular air flow/ inflatable system from your phone. In order to prevent bedsores and facilitate the work of nurses. Smartbeddo inflate according each comand click you give from your mobile phone in order to accomodate patient in the best position.

who has done what beforehand?

To better orient my idea I have based on the Merav Gazit project. Using the design of the Soft Robotics Actuators from MIT Projects.

what materials and components will be required?

Silicona F20 plus S/.54.00

Hoses 6mm diameter S/.1.00/m ( I used 6 m)

Selenoid valves *4 S/.76.00 (S/.19.00 each)

Relay *4 S/16.00

Bluettoth S/20.00

Air compressor S/.270.00 (can we find cheaper)

White sealing tape S/1.00

Pillow S/.10.00

Power supply 24VDC S/30.00

Acrylic

MDF

where will they come from?

From Fab Lab Tecsup and local supplier.

how much will it cost?

It will cost $140

what parts and systems will be made?

silicone modules design, joints with 3D impression, conectivity boards, programation, electronical design

what processes will be used?

design process, fabrication process, electronic process, programation process, interface process.

what have you learned?

I think I've learned a lot from all the ocntents developed during the Fab Academy here in Tecsup. I have to improve my mechanical design skill.

what questions need to be answered?

How could improve the quality of my prototype through better material and technology more industrially applied.

how will it be evaluated?

If the integrate system works inflating both sides
